TP-Link EAP773 OMADA WiFi7 AP (BE11000,2,4GHz/5GHz/6GHz,1x10GbELAN,1xPoE+)
Popis a parametre
TP-Link EAP773 OMADA WiFi7 AP (BE11000,2,4GHz/5GHz/6GHz,1x10GbELAN,1xPoE+)
TP-Link EAP773
Přístupový bod BE11000 Tri-Band WiFi 7 pro montáž na strop
- BE11000 Tri-Band Wi-Fi 7: 5760 Mbps (6 GHz) + 4320 Mbps (5 GHz) + 574 Mbps (2,4 GHz). Ukládání do vyrovnávací paměti již nebude problém.
- Jasné pásmo 6 GHz: Přináší čistší a širší pásmo k vaší Wi-Fi.
- 1× 10G port: Odemkněte plný potenciál Wi-Fi 7.
- Šířka pásma 320 MHz: Šířka pásma až 320 MHz umožňuje mnohem více současných přenosů při nejvyšší možné rychlosti.
- Nízká latence a interference: Multi-Link Operation a Multi-RUs zajišťují vysoký výkon vaší sítě.
- Pokročilé funkce:Podporuje centralizovanou správu, síť a bezproblémový roaming.
Stránky produktu: https://www.tp-link.com/sg/business-networking/omada-sdn-access-point/eap773/
Technické specifikace
HARDWARE FEATURES | |
Interface | 1× 10G Ethernet Port |
Button | Reset |
Power Supply | 802.3at PoE or 12V/2.5A DC |
Power Consumption | Support Smart Power Comsuption Management • 25.94 W (802.3bt, full functionality); • 22.57 W (12/2.5A, full functionality); • 23.4 W (802.3at decrease 6GHz Power); • 10.1 W (802.3af, radio off, only main chip and LAN working) |
Dimensions ( W x D x H ) | 8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm) |
Antenna Type | • 2.4 GHz: 2× 3.0 dBi • 5 GHz: 2× 3.0 dBi • 6 GHz: 2× 3.0 dBi |
Bluetooth | 1 × 4.0 dBi, Bluetooth 5.2 *Firmware update may be required. |
Mounting | Ceiling / Wall Mounting (Kits Included) |
WIRELESS FEATURES | |
Wireless Client Capacity | 2 GHz: 128** 5 GHz: 128** 6 GHz: 128** |
Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax/be |
Frequency | 6 GHz, 5 GHz, and 2.4 GHz |
Signal Rate | 574 Mbps (2.4 GHz) + 4320 Mbps (5 GHz) + 5760 Mbps (6 GHz)† |
Wireless Functions | • MLO‡ • 4K-QAM‡ • MU-MIMO‡ • HE320‡ • Mesh? • BSS Coloring‡ • OFDMA‡ • Load Balance • Band Steering • Beamforming • Airtime Fairness • Multiple SSIDS:24(8 on each band) • Wireless Schedule • Reboot Schedule • QoS(WMM) • Rate Limit • Static IP/Dynamic IP • RADIUS Accounting • MAC Authentication |
Wireless Security | • Captive Portal Authentication? • Access Control • Maximum number of MAC Filter: 4,000 • Wireless Isolation Between Clients • VLAN • Rogue AP Detection • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
Transmission Power | < 25 dBm (2.4 GHz) < 25 dBm (5 GHz) < 23 dBm (6 GHz) |
MANAGEMENT | |
Omada App | Yes |
Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller |
Cloud Access | Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller. |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP | v1, v2c, v3 |
System Logging Local/Remote Syslog | Yes |
Web-based Management | Yes |
OTHERS | |
Certification | CE, FCC, RoHS, IC |
Package Contents | • EAP773 • Installation Guide • Ceiling/Wall Mounting Kits Note: Power Adapter is NOT included. |
Environment | • Operating Temperature: 0 °C–40 °C (32 °F–104 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing; |
TP-Link EAP773 OMADA WiFi7 AP (BE11000,2,4GHz/5GHz/6GHz,1x10GbELAN,1xPoE+)
