TP-Link EAP623-Outdoor HD venkovní OMADA WiFi6 AP (AX1800,2,4GHz/5GHz,1xGbELAN,1xPoE-in)
Popis a parametre
TP-Link EAP623-Outdoor HD venkovní OMADA WiFi6 AP (AX1800,2,4GHz/5GHz,1xGbELAN,1xPoE-in)
TP-Link EAP623-Outdoor HD
AX1800 vnitřní/venkovní Wi-Fi 6 přístupový bod
- Až 1,8 Gbps WiFi 6 rychlostí: 574 Mbps na 2,4 GHz + 1201 Mbps na 5 GHz
- Podporuje technologie WiFi 6 1024-QAM a OFDMA atd
- Konektivita s vysokou hustotou až 1 000+ klientů
- Dlouhý dosah pokrytí s vysoce výkonným zesilovačem a chytrými anténami.
- Krytí IP67 odolné proti povětrnostním vlivům pro různá venkovní prostředí.
- Pokročilé funkce: Centralizovaná správa, síť Omada a bezproblémový roaming.
- Napájení PoE+: Podporuje 802.3at PoE (adaptér není součástí dodávky)
Stránky produktu: https://www.tp-link.com/cz/business-networking/omada-wifi-outdoor/eap623-outdoor-hd/
Technické specifikace
| HARDWARE FEATURES | |
| Interface | 1x Gigabit Ethernet Port |
| Button | Reset |
| Power Supply | • 802.3at PoE • 48V Passive PoE Note: PoE adapter is not included. |
| Dimensions ( W x D x H ) | 11.0 x 4.2 x 2.2 in (280.4 × 106.5 × 56.8 mm) |
| Antenna Type | 2× Internal Dual-Band Omni Antennas • 2.4 GHz: 4.0 dBi; • 5 GHz: 5.0 dBi |
| Weatherproof Enclosure | IP67 |
| Mounting | Pole/Wall Mounting (Kits included) |
| WIRELESS FEATURES | |
| Concurrent Clients | 1,020+** |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 5 GHz, and 2.4 GHz |
| Signal Rate | • 5 GHz: Up to 1201 Mbps • 2.4 GHz: Up to 574 Mbps |
| Wireless Functions | • Mesh? • Seamless Roaming? • Automatic Channel Assignment • Load Balance • Band Steering • Beamforming • Airtime Fairness • Multiple SSIDs:16 (8 for each band) • Wireless Statistics • Wireless Schedule • Reboot Schedule • RADIUS Accounting • MAC Authentication • Static IP/Dynamic IP |
| Wireless Security | • VLAN • Access Control • Rogue AP Detection • Captive Portal Authentication? • Maximum number of MAC Filter: 4,000 • Wireless Isolation between Clients • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise • 802.1X Support |
| Transmission Power | • CE: < 20 dBm (2.4 GHz, EIRP), < 30 dBm (5 GHz, EIRP); • FCC: < 25 dBm (2.4 GHz), < 25 dBm (5 GHz) |
| MANAGEMENT | |
| Omada App | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| Centralized Management | • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller • Omada Cloud-Based Controller |
| Cloud Access | Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| SSH | Yes |
| Web-based Management | Yes |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | • EAP623-Outdoor HD • Installation Guide • Mounting Kit • Waterproof Kit |
| Environment | • Operating Temperature: -30 °C–70 °C (-22 °F–158 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing |
