ASUS zvuková karta Xonar U7 MK II, sound card, USB 2.0
Popis a parametre
ASUS zvuková karta Xonar U7 MK II, sound card, USB 2.0
Xonar U7 MKII
Xonar U7 MKII 7.1 USB sound card with headphone amplifier, 192kHz/24-bit HD sound, 114dB SNR
- True 7.1-channel, 192kHz/24-bit HD surround sound with a 114dB SNR from a compact, USB-powered device
- Integrated headphone amplifier boosts sound and reveals musical details
- Dedicated headphone and mic volume controls enable instant audio adjustments for better gaming and media streaming experiences
- Clickable volume control knob for convenient switching between headphone and speaker output
- Sonic Studio software suite with intuitive, single-screen interface and Sonic Radar Pro for mapping opponent locations in first-person shooters
Interface
USB
SNR(dB)
114dB
THD+N
0.0006 %(104 dB)
Headphone output power
Line output (RCA, 3.5) : 1 Vrms (2.828 Vp-p)
Headphone output : 1.3 Vrms (3.677 Vp-p)
I/O
4 x 3.5 mm jack (1/8") (Headphone out /Side out/Center-Subwoofer out/Rear out)
2 x RCA (Un-Balanced)
1 x 3.5 mm jack (1/8") (Line-in/ Mic-in combo)
1 x S/PDIF out (1 x Coaxial)
Audio Processor
Cmedia 6632AX
D-A Converter
Cirrus Logic CS4398
Cirrus Logic CS4362
A-D Converter
Cirrus Logic CS5361
ASIO
Yes
Accessory
S/PDIF adapter x 1
Quick start guide x 1
USB cable x 1
Operation System
Windows10(32/64bit)
Windows8.1(32/64bit)
Windows7(32/64bit)
